INTERNAL CABLE ROUTING HEADSETS
C554A
ZS56/28.6 | ZS56/40
➤ Alloy Cap/Cup
➤ Sealed Bearings
➤ Tapered Steerer
➤ Angle Limited
Technical Diagram
C660A
ZS56/28.6 | ZS66/45.8
➤ Alloy, Sealed Bearings
➤ 1-1/8″ to 1.8″
➤ Tapered Head Tube & Steerer
➤ Top Nut: 1-1/8″
➤ Cup O.D.: 56/66
➤ Crown Cone: 45.8
➤ Height: 11.2
➤ Weight: 175g
Technical Diagram
C550A
ZS56/28.6 | ZS56/40
➤ Alloy, Sealed Bearings
➤ 1-1/8″ to 1.5″
➤ Tapered Steerer
➤ Top Nut: 1-1/8″
➤ Cup O.D.: 56
➤ Crown Cone: 39.8
➤ Height: 11.5
➤ Weight: 158g
Technical Diagram
C522A
IS52/28.6 | ZS52/40
➤ Alloy, Sealed Bearings
➤ 1-1/8″ to 1.5″
➤ Tapered Steerer
➤ Top Nut: 1-1/8″
➤ Bearing O.D.: 51.8
➤ Crown Cone: 39.8
➤ Height: 11.5
➤ Weight: 136g
Technical Diagram
C522A-1
IS52/28.6 | ZS52/40
➤ Alloy, Sealed Bearings
➤ 1-1/8″ to 1.5″
➤ Tapered Steerer
➤ Top Nut: 1-1/8″
➤ Bearing O.D.: 51.8
➤ Crown Cone: 39.8
➤ Height: 11.5
➤ Weight: 138g
Technical Diagram
C522A-3
IS52/28.6 | ZS52/40
➤ Alloy, Sealed Bearings
➤ 1-1/8″ to 1.5″
➤ Tapered Steerer
➤ Top Nut: 1-1/8″
➤ Bearing O.D.: 51.8
➤ Crown Cone: 39.8
➤ Height: 11.5
➤ Weight: 140g
Technical Diagram
C525A
IS52/28.6 | ZS52/40
➤ Alloy, Sealed Bearings
➤ 1-1/8″ to 1.5″
➤ Tapered Steerer
➤ Top Nut: 1-1/8″
➤ Bearing O.D.: 51.8
➤ Crown Cone: 39.8
➤ Height: 14
➤ Weight: 138g
Technical Diagram
